OpenAPI Quick Start

Welcome to the Bika.ai OpenAPI Quick Start Guide!

This document provides a series of examples to help you get started with the Bika.ai API and SDK. Each section contains code snippets for common operations, including fetching data, creating records, updating records, deleting records, and using automation.

API Reference Document

Click to go 👉 Bika.ai API Reference

Basic Concepts

Before using this Open API, we need to first understand the structure and object hierarchy of Bika.ai.

Space
- Node Resources：
  - Database
  - Automation
  - Dashboard
  - Document
  - AI Chatbot
  - ……

The Space is your workspace. It encompasses all the node resources we've previously mentioned, including databases, automation facilities, dashboards, and additional components. When leveraging the Open API, data retrieval must be carried out in accordance with this structure.

For instance, if you aim to obtain the database C represented by node B within Space A, the API would be similar to spaceA.nodeB->resoure->databaseB.

Note that the node ID is equivalent to the resource ID; for instance, Node ID and Database ID are the same.

For a URL like:

https://bika.ai/space/spcND68gdMMZBmGK67gvqNVX/node/datJubyEnetNFd3UQ6gSeq7U/viwYHuzUxRngq5igMkw9PPIX

SpaceId: spcND68gdMMZBmGK67gvqNVX

NodeID = DatabaseID: datJubyEnetNFd3UQ6gSeq7U

The associated TypeScript SDK is designed in an object-oriented style, which greatly simplifies your code.

Also, the space UI follows the above data structure layer.

For details, please read the homepage of the help document at https://bika.ai/help to view the overall UI introduction of the Space.

cURL

OpenAPI is composed of the HTTP protocol, and below are examples of how to call Bika.ai's OpenAPI using the cURL command line tool.

Please checkout the Bika.ai API Reference for more API details.

You can access these OpenAPI endpoints using any HTTP client that supports them, such as cURL, Python Requests, Node.js axios, Rust reqwest, and others.

System

Retrieving System Meta Info

curl -X GET "https://bika.ai/api/openapi/bika/v1/system/meta" -H "Authorization: Bearer {YOUR_ACCESS_TOKEN}"

Response Example:

{
    "success": true,
    "code": 200,
    "message": "SUCCESS",
    "data": {
        "version": "1.0.0-release.0",
        "appEnv": "PRODUCTION",
        "hostname": "https://bika.ai",
        "headers": {
            "X-Forwarded-For": "35.96.5.64",
            "User-Agent": "curl/8.4.0"
        }
    }
}

Retrieving Space List

curl -X GET "https://bika.ai/api/openapi/bika/v1/spaces" -H "Authorization: Bearer {YOUR_ACCESS_TOKEN}"

Database

Get Records

Gets a list of records from the specified database. Assuming we know that the ID of the space is {SPACE_ID},and the ID of the database is {NODE_ID}, here's an example of a cURL call:

curl -X GET 'https://bika.ai/api/openapi/bika/v1/spaces/{SPACE_ID}/resources/databases/{NODE_ID}/records' \
-H "Authorization: Bearer {YOUR_ACCESS_TOKEN}"

Creating a New Record

Assume we have obtained the ID of a certain space as {SPACE_ID}, node ID as {NODE_ID}, and database ID always equals to node ID. Here is an example of creating a new record:

curl -X POST "https://bika.ai/api/openapi/bika/v1/spaces/{SPACE_ID}/resources/databases/{NODE_ID}/records" \
    -H "Authorization: Bearer {YOUR_ACCESS_TOKEN}" \
    -H "Content-Type: application/json" \
    -d '{
        "cells": {
            "Name": "New record",
            "Description": "This is a new database record"
        }
    }'

Updating a Record

Assume the record ID is {RECORD_ID}. The example of updating a record is as follows:

curl -X PATCH "https://bika.ai/api/openapi/bika/v1/spaces/spcpPuRJJC4CZOwzB9Vlwmja/resources/databases/datkW11Rxx6hFJO924ECNxLk/records" \
    -H "Authorization: Bearer bkteM550dHdXyTKN4Wkp59pYX8JD5cDU7rB" \
    -H "Content-Type: application/json" \
    -d '{
        "id": "recpx8ZUBHmRFuD0fGTObHxL",
        "cells": {
            "Task": "Updated description field column"
        }
    }'

Deleting a Record

curl -X DELETE "https://bika.ai/api/openapi/bika/v1/spaces/{SPACE_ID}/resources/databases/{NODE_ID}/records/{RECORD_ID}" \
    -H "Authorization: Bearer {YOUR_ACCESS_TOKEN}"

Others

Upload attachments

Note: This interface needs to be used in conjunction with the "Create Record" or "Update Record" interface. After the attachment is uploaded, a return value (located in the data attribute of the response body) will be obtained. Use this value as the value of the field where the attachment is to be inserted in the record, and write it into the database together through the "Create Record" or "Update Record" interface.

curl -X POST "https://bika.ai/api/openapi/bika/v1/spaces/{SPACE_ID}/attachments" \
-H "Authorization: Bearer {YOUR_ACCESS_TOKEN}" \
-F 'file=@./example.png'

Listing Automation Triggers

Assume the node ID is {NODE_ID}. The example is as follows:

curl -X GET "https://bika.ai/api/openapi/bika/v1/spaces/{SPACE_ID}/resources/automation/{NODE_ID}/triggers" \
    -H "Authorization: Bearer {YOUR_ACCESS_TOKEN}"

Registering an Outbound Webhook

curl -X POST "https://bika.ai/api/openapi/bika/v1/spaces/{SPACE_ID}/outgoing-webhooks" \
    -H "Authorization: Bearer {YOUR_ACCESS_TOKEN}" \
    -H "Content-Type: application/json" \
    -d '{
        "eventType": "ON_RECORD_CREATED",
        "name": "Create webhook",
        "description": "Example trigger when a new record is created",
        "callbackURL": "https://your - custom - callback - url.com"
    }'

Python HTTP Client

Installing Dependencies

First, ensure that the requests library is installed. You can use the following command to install it:

pip install requests

System

Retrieving System Metadata

import requests

access_token = "{YOUR_ACCESS_TOKEN}"
url = "https://bika.ai/api/openapi/bika/v1/system/meta"
headers = {
    "Authorization": f"Bearer {access_token}"
}
response = requests.get(url, headers = headers)
print(response.json())

Retrieving Space List

import requests

access_token = "{YOUR_ACCESS_TOKEN}"
url = "https://bika.ai/api/openapi/bika/v1/spaces"
headers = {
    "Authorization": f"Bearer {access_token}"
}
response = requests.get(url, headers = headers)
spaces = response.json()["data"]
print(spaces)

Database

Retrieving Database Records

import requests
import json

access_token = "{YOUR_ACCESS_TOKEN}"
space_id = "{SPACE_ID}"
node_id = "{NODE_ID}"
database_id = "{DATABASE_ID}"
url = f"https://bika.ai/api/openapi/bika/v1/spaces/{space_id}/resources/databases/{node_id}/records"
headers = {
    "Authorization": f"Bearer {access_token}",
    "Content-Type": "application/json"
}
data = {
    "fields": {
        "Name": "New record",
        "Description": "This is a new database record"
    }
}
response = requests.post(url, headers = headers, data = json.dumps(data))
print(response.json())

Creating a New Record

import requests
import json

access_token = "{YOUR_ACCESS_TOKEN}"
space_id = "{SPACE_ID}"
node_id = "{NODE_ID}"
database_id = "{DATABASE_ID}"
url = f"https://bika.ai/api/openapi/bika/v1/spaces/{space_id}/resources/databases/{node_id}/records"
headers = {
    "Authorization": f"Bearer {access_token}",
    "Content-Type": "application/json"
}
data = {
    "cells": {
        "Name": "New record",
        "Description": "This is a new database record"
    }
}
response = requests.post(url, headers = headers, data = json.dumps(data))
print(response.json())

Updating a Record

import requests
import json

access_token = "{YOUR_ACCESS_TOKEN}"
space_id = "{SPACE_ID}"
node_id = "{NODE_ID}"
database_id = "{DATABASE_ID}"
record_id = "{RECORD_ID}"
url = f"https://bika.ai/api/openapi/bika/v1/spaces/{space_id}/resources/databases/{node_id}/records"
headers = {
    "Authorization": f"Bearer {access_token}",
    "Content-Type": "application/json"
}
data = {
    "id": "recpx8ZUBHmRFuD0fGTObHxL",
    "cells": {
        "Task": "Updated description field column"
    }
}
response = requests.patch(url, headers = headers, data = json.dumps(data))
print(response.json())

Deleting a Record

import requests

access_token = "{YOUR_ACCESS_TOKEN}"
space_id = "{SPACE_ID}"
node_id = "{NODE_ID_DATABASE_ID}"
record_id = "{RECORD_ID}"
url = f"https://bika.ai/api/openapi/bika/v1/spaces/{space_id}/resources/databases/{node_id}/records/{record_id}"
headers = {
    "Authorization": f"Bearer {access_token}"
}
response = requests.delete(url, headers = headers)
print(response.json())

Others

Listing Automation Triggers

import requests

access_token = "{YOUR_ACCESS_TOKEN}"
space_id = "{SPACE_ID}"
node_id = "{NODE_ID}"
url = f"https://bika.ai/api/openapi/bika/v1/spaces/{space_id}/nodes/{node_id}/automation/triggers"
headers = {
    "Authorization": f"Bearer {access_token}"
}
response = requests.get(url, headers = headers)
triggers = response.json()["data"]
print(triggers)

Registering an Outbound Webhook

import requests
import json

access_token = "{YOUR_ACCESS_TOKEN}"
space_id = "{SPACE_ID}"
url = f"https://bika.ai/api/openapi/bika/v1/spaces/{space_id}/outgoing-webhooks"
headers = {
    "Authorization": f"Bearer {access_token}",
    "Content-Type": "application/json"
}
data = {
    "eventType": "ON_RECORD_CREATED",
    "name": "Create webhook",
    "description": "Example trigger when a new record is created",
    "callbackURL": "https://your - custom - callback - url.com"
}
response = requests.post(url, headers = headers, data = json.dumps(data))
print(response.json())

Through the above cURL and Python examples, developers can more conveniently use the Bika.ai OpenAPI to perform various operations. For more detailed information, please refer to the Bika.ai API documentation.

TypeScript / JavaScript SDK

Bika.ai offers an official TypeScript/JavaScript SDK for convenient object-oriented programming when using Bika.ai's OpenAPI.

Prerequisites

Node.js installed on your machine.
Bika.ai API Token: Sign up on Bika.ai and get your API token from your user settings.

Installation

First, install the Bika.ai SDK using npm:

npm install bika.ai
# or
yarn add bika.ai
pnpm add bika.ai

Example 1: Fetch Database Records

This example demonstrates how to fetch spaces, nodes, and records.

import { Bika } from 'bika.ai';

const bika = new Bika({
    apiKey: '__PASTE_YOUR_API_TOKEN_FROM_USER_SETTING__',
    baseURL: 'https://bika.ai/api/openapi/bika',
});

async function fetchRecords() {
    try {
        const spaces = await bika.space.list();
        const space = spaces[0];
        const nodes = await space.nodes.list();
        const node = nodes.find((node) => node.resourceType === 'DATABASE');
        const database = await node?.asDatabase();
        const records = await database?.records.list();
        console.log('Records:', records);
    } catch (error) {
        console.error('Error fetching data:', error);
    }
}

fetchRecords();

Example 2: Create a New Record

Use this example to create a new record in your database.

import { Bika } from 'bika.ai';

const bika = new Bika({
    apiKey: '__PASTE_YOUR_API_TOKEN_FROM_USER_SETTING__',
    baseURL: 'https://bika.ai/api/openapi/bika',
});

async function createRecord() {
    try {
        const spaces = await bika.space.list();
        const space = spaces[0];
        const nodes = await space.nodes.list();
        const node = nodes.find((node) => node.resourceType === 'DATABASE');
        const database = await node?.asDatabase();
        const newRecord = await database?.records.create({
            cells: {
                Name: 'New record',
            },
        });

        console.log('New Record Created:', newRecord);
    } catch (error) {
        console.error('Error creating record:', error);
    }
}
createRecord();

Example 3: Update a Record

This example updates an existing record.

import { Bika } from 'bika.ai';

const bika = new Bika({
    apiKey: '__PASTE_YOUR_API_TOKEN_FROM_USER_SETTING__',
    baseURL: 'https://bika.ai/api/openapi/bika',
});

async function updateRecord(recordId: string) {
    try {
        const spaces = await bika.space.list();
        const space = spaces[0];
        const nodes = await space.nodes.list();
        const node = nodes.find((node) => node.resourceType === 'DATABASE');
        const database = await node?.asDatabase();
        const updatedRecord = await database?.records.update({
            id: recordId,
            cells: {
                Name: 'Updated Record',
            },
        });

        console.log('Database:', database);
        console.log('Record Updated:', updatedRecord);
    } catch (error) {
        console.error('Error updating record:', error);
    }
}

updateRecord('__REPLACE_WITH_RECORD_ID__');

Example 4: Delete a Record

Use this example to delete a specific record.

import { Bika } from 'bika.ai';

const bika = new Bika({
    apiKey: '__PASTE_YOUR_API_TOKEN_FROM_USER_SETTING__',
    baseURL: 'https://bika.ai/api/openapi/bika',
});

async function deleteRecord(recordId: string) {
    try {
        const spaces = await bika.space.list();
        const space = spaces[0];
        const nodes = await space.nodes.list();
        const node = nodes.find((node) => node.resourceType === 'DATABASE');
        const database = await node?.asDatabase();
        await database?.records.delete(recordId);

        console.log('Database:', database);
        console.log('Record Deleted:', recordId);
    } catch (error) {
        console.error('Error deleting record:', error);
    }
}

deleteRecord('__REPLACE_WITH_RECORD_ID__');

Example 5: List Automation Triggers

This example shows how to list automation triggers.

import { Bika } from 'bika.ai';

const bika = new Bika({
    apiKey: '__PASTE_YOUR_API_TOKEN_FROM_USER_SETTING__',
    baseURL: 'https://bika.ai/api/openapi/bika',
});

async function listTriggers() {
    try {
        const spaces = await bika.space.list();
        const space = spaces[0];
        const nodes = await space.nodes.list();
        const node = nodes.find((node) => node.resourceType === 'AUTOMATION');
        const automation = await node?.asAutomation();
        const triggers = await automation?.triggers.list();

        console.log('Triggers:', triggers);
    } catch (error) {
        console.error('Error listing triggers:', error);
    }
}
listTriggers();

Example 6: Register an Outgoing Webhook

This example demonstrates how to register an outgoing webhook.

import { Bika } from 'bika.ai';

const bika = new Bika({
    apiKey: '__PASTE_YOUR_API_TOKEN_FROM_USER_SETTING__',
    baseURL: 'https://bika.ai/api/openapi/bika',
});

async function registerWebhook() {
    try {
        const spaces = await bika.space.list();
        const space = spaces[0];
        const outgoingWebhook = await space.outgoingWebhooks.register({
            eventType: 'ON_RECORD_CREATED',
            name: 'Create webhook',
            description: 'Exampple trigger when a new record cretaed',
            callbackURL: 'https://your-custom-callback-url.com',
        });

        console.log('Webhook Registered:', outgoingWebhook);
    } catch (error) {
        console.error('Error registering webhook:', error);
    }
}
registerWebhook();

Example 7: Embeded Bika.ai's UI（Coming soon）

Here are examples of embedding Bika.ai's UI into your own application.

If you want to incorporate Bika.ai's robust UI for databases, documents, and more, you can utilize the embed link API.

Generate an embed link to obtain a URL, and then use an <iframe> in your application.

import { Bika } from 'bika.ai';

const bika = new Bika({
    apiKey: '__PASTE_YOUR_API_TOKEN_FROM_USER_SETTING__',
    baseURL: 'https://bika.ai/api/openapi/bika',
});

async function createEmbedLink(resourceId: string) {
    try {
        const spaces = await bika.space.list();
        const space = spaces[0];
        const embedLink = await space.embedLinks.create({
            objectType: 'NODE_RESOURCE',
            objectId: resourceId,
          });

        console.log('Embed Link:', embedLink);
    } catch (error) {
        console.error('Error creating embed link:', error);
    }
}
createEmbedLink('__NODE_RESOURCE_ID_YOU_WANT_TO_EMBED__');

// else
const embedLinks = await space.embedLink.list();
const deleteEmbedLink = await space.embedLink.delete({id: [embedLink.id](https://embedlink.id/)});

After creating an embedded Bika.ai UI, you can use the <iframe> tag to display it on your web page. Here's a simple example of how to do this:

<iframe src="YOUR_EMBEDDED_UI_URL" width="800" height="600"></iframe>

Replace YOUR_EMBEDDED_UI_URL with the actual URL of the embedded Bika.ai UI you created. You can adjust the width and height attributes according to your layout needs.

Conclusion

This Quick Start Guide provides basic examples to help you interact with the Bika.ai OpenAPI and SDK effectively. You can modify and expand these examples as needed for your specific use cases. For more detailed information, refer to the Bika.ai API Documentation.

Happy coding!

Recommend AI Automation Templates

AI Invoice Information Recognition

This AI Invoice Information Recognition template uses invoice OCR AI to automatically extract key fields from invoice images and turn manual entry into financial data automation. Set up an end-to-end invoice processing workflow that captures invoice numbers, dates, amounts, and taxes, and stores everything in a structured database. Extend the same flow to receipt data extraction and purchase order processing so finance teams, SMEs, and accountants can handle bulk documents faster, reduce errors, and keep all financial data accurate and searchable.

Telegram Scheduled Notifications

Automate Telegram reminders and notifications for groups, channels, or private chats. Keep your team informed, improve collaboration, and manage tasks efficiently with Bika.ai’s Telegram bot automation.

Bank Statement Attachment to Database

Manually upload a PDF attachment of the bank statement, use image recognition technology to extract the total expenditure and stock data, and generate data records into the Bika database

Coming soon

Resume Analyzer

HR AI Assistant is designed to streamline your resume workflow. It automatically extracts key candidate details from resumes (screenshots or PDFs) and organizes them into your datasheet. Simply upload a resume, and the assistant will handle the rest — making your hiring process faster, more accurate, and more efficient.

AI Marketing Campaign Analysis

The AI Marketing Campaign Analysis template is a campaign tracking template and AI marketing workflow that centralizes marketing data integration in one marketing campaign database. Track advertising campaign metrics and marketing KPI tracking across channels, and let marketing report automation generate and deliver clear summaries to your team. Improve marketing team collaboration with shared views of campaigns, goals, statuses, and results so everyone can act on up-to-date performance insights instead of manual spreadsheets.

Business Contract Management

Streamline your entire contract lifecycle with the Business Contract Management template. This centralized contract management system serves as an all-in-one contract database and centralized contract repository for tracking contract details, approvals, and activities. Automate key processes through a contract approval workflow and contract workflow management, ensuring accuracy, transparency, and collaboration across teams. Ideal for project contract management, this template simplifies service request tracking, reduces manual work, and improves efficiency from contract submission to expiration reminders.

OpenAPI Quick Start

Example 7: Embeded Bika.ai's UI（Coming soon）

Recommend AI Automation Templates

On this page
